IGBT Control Medium Frequency Induction Heater for gear shaft quenching (GYM-80AB)

    Buy cheap IGBT Control Medium Frequency Induction Heater for gear shaft quenching (GYM-80AB) from wholesalers

    Buy cheap IGBT Control Medium Frequency Induction Heater for gear shaft quenching (GYM-80AB) from wholesalers
    • Buy cheap IGBT Control Medium Frequency Induction Heater for gear shaft quenching (GYM-80AB) from wholesalers

    IGBT Control Medium Frequency Induction Heater for gear shaft quenching (GYM-80AB)

    Ask Lasest Price
    Brand Name : GY
    Model Number : GYM-80AB
    Certification : SGS,FCC,ROSH,CE
    Delivery Time : within 7 workdays
    Payment Terms : 100%TT,
    Supply Ability : 1000SET Per Month
    • Product Details
    • Company Profile

    IGBT Control Medium Frequency Induction Heater for gear shaft quenching (GYM-80AB)

    IGBT Control Medium Frequency Induction Heater for gear shaft quenching (GYM-80AB)

    Application of Induction Heating Equipment:

    A. Heating (hot forging, hot fitting and melting):
    B. Heat Treatment (surface quench):
    C. Welding (braze welding, silver soldering and brazing)
    D. Annealing (tempering and modulation):

    Main characteristics:


    1 Siemens IGBT module and Inverting technologies of third generation been used;

    Higher reliability and lower maintenance cost.


    2 100% Duty cycle, continuous working is allowed at maximum power output.


    3Display of heating power and heating current and oscillating frequency;


    4 Simple to install, Installation can be done by unprofessional person very easily;


    5 Small size &Light weight


    6 Advantages of the model with timer: The power and the operating time of the heating period

    and the retain period can be preset respectively, to realize a simple heating curve, this model is

    suggested to use for batch production to improve the repeatability;


    7 Constant current or constant power status can be selected accordingly to achieve higher

    heating efficiency;


    Parameter

    ModelGYM-80AB (Three phase)
    work power340V-430V
    Maximum input current120A
    Output power80KW
    fluctuating frequency1-10KHZ
    output current400-3500A
    the flow rate of cooling water0.08-0.16Mpa 9L/Min
    water temperature protection point50C
    product sizemain : 725 X 600 X 1050 mm
    transformer : 850 X 420 X 650 mm
    net weightmain : 85kgs
    transformer : 65kgs
