Induction Heating Machine with CNC Hardening Machine For Steel Bar

    Buy cheap Induction Heating Machine with CNC Hardening Machine For Steel Bar from wholesalers

    Buy cheap Induction Heating Machine with CNC Hardening Machine For Steel Bar from wholesalers
    • Buy cheap Induction Heating Machine with CNC Hardening Machine For Steel Bar from wholesalers

    Induction Heating Machine with CNC Hardening Machine For Steel Bar

    Ask Lasest Price
    Brand Name : GY
    Certification : CE,SGS,FCC,ROSH
    Model Number : GY-CNC1000
    Delivery Time : 20workdays
    Payment Terms : 100%TT
    Supply Ability : 300PC/MONTH
    • Product Details
    • Company Profile

    Induction Heating Machine with CNC Hardening Machine For Steel Bar

    Induction Heating Machine with CNC Hardening Machine For Steel Bar

    Induction Heat Hardening Machine use for hardening wide range application,such as shaft,gear,rollers,pipes,pump fitting,bearing,gear teeth,etc.Customs design for customer requirement.

    Capability characteristic:

    • Adopt beeline bearing, high precision, little attrition, life length.
    • Ball bearing pole driving, serve electrical driving, high precision, life length.
    • Numerical control system is controling, keyboard input, memory quenching procedure,
    • working procedure is auto controling.
    • Actualize shift, running calm, high orientation precision. Operation easily.

    Parameter:

    Maximum clamping parts length1000mm
    Maximum quenching diamention100mm
    Maximum workpiece weight50kg
    Workpiece travel speed1-30mm/s
    Workpiece updown speed120mm/s
    Rotating speed1-200r/min
    Cooling wayimmersion ,spray,
    Machine size after packing2440*1320*900MM
    Operationautomatically or manually

    ModelGYS-100AB (Three phase)
    Work power340V-430V
    Maximum input current150A
    Output power100KW
    Fluctuating frequency20-50khz
    Output current400-4000A
    The flow rate of cooling water:0.08-0.16Mpa 10L/Min
    Water temperature protection point50C
    Product sizemain : 790x695x1060mm
    transformer : 865x420x650mm
    Net weightmain : 100kgs
    transformer : 70kgs

    About service question:
    Q: Why choose GuangYuan Company?
    A: We are manufacture which had in this filed for nearly 20 years.No matter quality,

    price,service,delivery time,we all have large advantage.

    Q:How to choose suiteble machine?
    A:You can tell us your application,need forging,hardening,welding,melting or other,

    pass me workpiece material & size,Temperature requirement and heating time requirement.

    Then we will recommend fit machine for you reference.

    Q:How about the machine payment term&delivery time&Shipping term?
    A: Our company payment term accept T/T,Western Union,L/C and so on.Small machine delivery

    time is 3~7 workdays.Big machine delivery time 15~25 workdays.Shipping term accept EXW,FOB,

    CIF and so on.

    Q:How about the machine warranty?
    A:Our goods support one year warranty not by personal purpose,support technical service all life.
    During the warranty,if machine have problem need change spare parts,we can replace for you

    charge free.
